Came with the original packaging, with PSU, Microdrive tapes, software, and manuals. There was also an additional Minerva ROM, and a Scart monitor adapter included.
The QL had a palette of only 8 colors and no sound chip, making it even inferior to the Spectrum 128K regarding games.
Restauration Works
ROM port cover was missing, and was replaced by a 3D printed replica.
Top case and keyboard was cleaned.
Original keyboard membrane was brittle due to old age, and was replaced by a new replica one.
Original UK style power plug has been replaced with a DIY European plug. I didn’t trust the new plug, so I replaced it again with an European plug with a proper pull relief.
Known Issues
The left microdrive motor has a damaged bearing, and needs replacement.
The capacitors are the original ones, which might have dried out.
The original 7805 is working at its load limit and needs a big heatsink. It should be replaced with a Traco Power TSR-2 DC/DC converter.
Bought a 512 KB memory expansion that just waits to be mounted.
History
2022-08-18: Purchased an internal 512KB RAM expansion.
2022-01-12: Purchased a NOS Mabuchi motor for the microdrive.
2021-12-30
Case cleaned
Replaced tacky EU power plug with a good one (with proper pull relief)
